Glyph-H2 Overview

Overview of Glyph-H2​

Introducing the Glyph-H2, a super efficient microcontroller development board packed with features for your next IoT project! With the robust capabilities of the ESP32-H2 chip, the Glyph-H2 is designed to provide reliable performance and extensive connectivity options in a compact form factor.

PCBCUPID_esp32h2-overview_result

  • Dimensions: Measures 50.8mm x 22.8mm x 1.6mm (without headers soldered)

  • Processor: ESP32-C3 32-bit RISC-V single-core processor running at 96 MHz @ 3.3V logic and power

  • RAM: 320 KB SRAM

  • Flash Memory: 4 MB SPI FLASH

  • GPIO: 19 GPIO pins with the following capabilities:

    • 12-bit ADCs
    • I2C
    • SPI
    • UART
    • USB Serial

    All the important peripherals, labeled for easy access.

  • Power Management:

    • USB Type C connector for power, programming, and serial port debugging
    • 3.3V regulator with 600mA peak current output
    • Built-in lipoly/li-ion charger with charging status indicator LED
    • Auto Switch between Battery & USB Power
    • Ability to Measure Battery Capacity
    • Ability to Turn off the battery with the onboard slide switch
    • Reverse Voltage protection with Diode

Additional Feature:

  • On-board LED (Connected to GPIO0)
  • On-board GLINK connector for easy integration with QWIIC, STEMMA QT compatible sensors & modules.
  • High Quality Reset and Bootloader button for easy access

Native Bootloader and Programming​

The Glyph-H2 features a built-in USB bootloader that makes programming new firmware easy and keeps the cost of the board down. On first time use, hold down the BOOT button while plugging it into USB, and it will appear as COM PORT in your device Manager. If you face any issue related to hardware not detecting on your system, please check out our troubleshooting guide here.

Connectivity​

The Glyph ESP32-H2 excels in connectivity with its built-in Bluetooth, Thread, Zigbee support. This makes it ideal for IoT applications, where reliable wireless communication is crucial.

PCBCUPID_H2_CONNECTIVITY_result

info

The wireless module on GLYPH board is CE & FCC Certified

Development Support​

The ESP32-H2 Glyph is supported by a variety of development environments, including:

  • Arduino.
  • MicroPython.
  • ESP-IDF (Espressif IoT Development Framework).
PCBCUPID_arduino_espressif_micropython_result

With extensive library support and a large community, getting started with the Glyph ESP32-H2 is straightforward.

Memory and Storage​

While the Glyph ESP32-H2 has 320KB onboard SRAM, it also relies on an external flash chip for program storage. On this board, there is 4 MB of flash memory, which is shared between the code, file storage and OTA.

ESP32-H2 Chip Features​

  • BluFi
  • RF Coexistence
  • ESP-BLE-MESH
  • ESP-WIFI-MESH

You can read more about it in ESP32H2 DATASHEET and ESP32H2 OFFICIAL documentation.
